D E M O 9 S 0 8 S V 1 6 / F L 1 6
J U N E
5 ,
2 0 0 9
U S E R G U I D E
SOFTWARE DEVELOPMENT
Software development requires the use of a compiler or an assembler supporting the HCS08
instruction set and a host PC operating a debug interface. CodeWarrior Development Studio
for Microcontrollers is supplied with this board for application development and debug.
Refer
to the supporting CodeWarrior documentation for details on use and capabilities.
DEVELOPMENT SUPPORT
Application development and debug for the target MC9S08SV16 or MC9S08FL16 is supported
through the integrated, Open-Source Background Debug Mode (BDM) interface. An optional
6-pos BDM_PORT header allows connecting an external HCS12/HCS08 BDM cable. The
BDM_PORT header is not installed in default configurations.
Integrated BDM
The DEMO9S08SV16/FL16 board features an integrated Open Source BDM (OSBDM-JM60)
based on the Freescale MC9S08JM60 MCU. The integrated USB BDM supports application
development and debugging via background debug mode.
The integrated BDM is fully
supported by CodeWarrior development tools.
The integrated USB BDM provides power and ground to the target board eliminating the need
to power the board externally. Power from the USB BDM is derived from the USB bus. The
integrated USB BDM is designed to sink a maximum of 300mA of current from the USB bus.
Therefore, total current consumption for the target board, and connected circuitry, must not
exceed 300mA . This current limit describes the current supplied by the USB cable to the
BDM circuit, the target board, and any connected circuitry. Excessive current drain will violate
the USB specification causing the bus to disconnect. Damage to the host PC USB hub or the
target board may result.
BDM_PORT Header
A compatible HCS12 BDM cable may also attach to the 6-pin BDM interface header
(BDM_PORT). Figure 2 below shows the pin-out for the BDM_PORT header.
Figure 2: BDM_PORT Header
BKGD
1
3
5
2 GND
4 RESET*
6 VDD
See the MC9S08SV16 or MC9S08FL16 Reference
Manual for details
NOTE: The BDM_PORT header is not installed in default configuration.
7
